High Performance 12 Lanes Alcohol Baby Wet Wipes Machine

Suitable material	Spunlace non-woven, hot rolling non-woven fabrics, Air-laid paper
Packing film	OPP/PE, PET/PE ,PET/AL/PE
GSM of raw material	40-80g/m2
capacity speed	3500-4800 psc/min (25-60bags)
Folding way	“Z”“W””C” type(pop up and non-pop up)
Size of product (unfolded)	(135-170)x(170-210) (MM)(LxW) (Modifiable)
Size of product (folded)	(135-170) x (90-110)(MM)(LxW) (Modifiable)
Electrical source	AC380V 50/60Hz
Power	15KW
Machine size	12200mmX2450mmX2200mm (L×W×H)
Machine weight	5000kg
Wetting system	one stainless steel water tank with agitator (preset full-auto continuous & circular stirring system); +one flow meter= the amount of sprayed liquid can be regulated
Control system:	Pre-programmed full-auto PLC control system; Frequency speed controlling (▲ provide all the programs to buyer)
Punching system	synchro rotary cutter
Counting system	Auto-counting ( operation interface setting)
Material Loading device:	2 holders sliting into12 channels, automatic tension controller

Production flow:

Raw material loading → vertical-folding → tissue wetting → tissue cutting → tissue counting and stacking → tissue delivery → film date Printing, punching and labeling→tissue packing → full auto plastic lid application
Product Type: baby wet wipes; household wet wipes （30-120pcs/pack)

This machine adopts full servo drive and PLC control system for operation. It’s made of raw material loading device, tension device, folding device, automatic wetting system, automatic counting device and slitting device, printing and punching device, labeling device, packing and gusseting device, full auto plastic lid application for finished products.
Stainless steel is applied to the cover of machine and main spare parts. The parts in contact with liquid and fabric are made of stainless steel. All the processes are finished on the machine without manual labor involved, so the finished product meets hygienic standard. The folding device is specially designed to make various folding ways feasible. It’s smart and speedy.

Rigor provides full aspects of after-sales services :

1.We welcome your sending technician to our factory to study and run the machine ordered before the machine is delivered.
2.After the machine arriving at your factory, we will send our engineer to your factory to help install and start up the machine and teach your workers to run the machine for you.
3.Our engineer can also stay in your factory to operate the machine for you for several months if you need.
4.We provide life-long after-sales service for our machines.
5.Our warranty extends to 12 months.
